Special Item

2013 DMG DMU 50 Ecoline 5-AXIS

Siemens 840D, 20.18.16", 8000 RPM, Cat 40, 17.4 HP, Trunnion Table, 30 Tools, Probe, ATLM, Chip Conveyor
Talk to a representative today!
(803) 548-8000

Product Details

  • X-Axis 19.6"
  • Y-Axis 17.72"
  • Z-Axis 15.74"
  • B-Axis (Table Swivel) -5 to +110 Degrees
  • C-Axis (Table Rotation) .001 Degrees
  • Table Size 24.8" x 19.7"
  • Spindle Speed 8000 RPM
  • Spindle Taper CAT 40
  • Spindle Motor 17.4 / 12.1 HP DC
  • Tools 30
  • Table Load Capacity 440 lbs.
  • Rapid Traverse Rates 945 IPM
  • Max Tool Diameter 3.15" / 5.12"
  • Max Tool Length 11.81"
  • Max Tool Weight 13.2 lbs.
  • Machine Weight 9020 lbs.
  • Spindle Torque 60.48 ft. lbs.

Product Features

  • Slimline with Operate 4.5 on Siemens 840D Solutionline CNC Control
  • 15" Color HIgh Resolution TFT
  • USB Ethernet
  • 5-Axis Machining Capability
  • Integral NC Swivel Rotary Table
  • 30 Position Side Mount Tool Changer
  • Chip Conveyor (Left Side Exit)
  • Renishaw Touch Probe
  • Renishaw Automatic Tool Length Measurement
  • 3D Work Piece Simulation
  • Full ASCII Keyboard
  • 11,465 Power On Hours
  • 4328 Cutting Hours
