1995 MAZAK M-4N/1500U

Mazatrol 640 Fusion, 2.75" Bar, 12" Chuck, 21.1" Max Dia, 25HP, 2200 RPM, Tail
Talk to a representative today!
(803) 548-8000

Product Details

  • Chuck Size 12"
  • Max Diameter Bar Capacity 2.75"
  • Max Swing Over Bed / Carriage 22" / 11"
  • Spindle Motor 25 / 20 HP AC
  • Spindle Speed 5 - 2200 RPM
  • Spindle Nose A2-8
  • Spindle Bore 3.15"
  • Tools 8 Front OD + 6 Rear ID
  • Rapid Traverse Rates (X / Z) 394 / 472 IPM
  • X-Axis Travel 21.7"
  • Z-Axis Travel 40.2"
  • Machine Dimensions (L x W x H) 165.9" x 114.2" x 94.5"
  • Machine Weight 11,000 lbs.
  • Distance Between Centers 60"
  • Max Turning Diameter 21.1"
  • Spindle Torque 918.2 ft. lbs.
  • Tailstock Taper MT#4

Product Features

  • Mazatrol T Plus CNC Control
  • 12" 3-Jaw Chuck
  • Tailstock
  • Coolant System
  • Splash/Chip Guard
  • Hardened Ways
  • 4977 Hours Total Power On Time
  • 1822 Hours Auto Operating Time
  • 1589 Hours Auto Cut Time
  • 1417 Hour Total Cut Time
